| Specifications |
|
| |
- 12(3)A 250V~
16(4)A 250V~
8(2)A 400V~
10(2)A 400V~
- Optional: Combination with a thermostat
- Optional: Internal connections between several contacts
- Temperature: 150º C
- 1E4 cicles (12A/16A)
5E4 cicles (12A)
- Optional: Combination to PCB with wiping contacts.
- PA. 6.6 Self extinguishing V-0 filled with 25% glass fibres.
- Contacts: Silver.
|
|
|
|
| |
Mounting Options |
|
| |
- Mounting options: 2 fixing screws M4 at 28 mm centres holes.
- Threaded bush fixing M12 x 1.5 L=5 - 6 - 9 mm.
|
|
| |
Shaft |
|
| |
- Spindle: Section 6mm x 4,6mm.
- Others by agreement. L max.=35 mm
|
|
| |
Terminals |
|
| |
|
